Overview
The Allen‑Bradley MPM-Series MPM‑A1304F‑SJ72AA 230V 3000 RPM Complete machine weighs 9.98 kg. Single-turn high-resolution absolute encoder. Free flange mounting holes (FF type). With standard flat key shaft extension, without shaft seal. SpeedTEC DIN quick right-angle connector, supporting 180° rotation wiring. 4-section iron core magnetic steel stack length.
Specification
| Item | Specification |
|---|---|
| Brand | Allen‑Bradley (Rockwell Automation) |
| Series | MPM Medium Inertia Permanent Magnet Servo Motor |
| Model | MPM-A1304F-SJ72AA |
| Product Status | Active |
| Compatible Drives | Kinetix 5500 / 5700 / 6000 (230V series) |
| Net Weight | 9.98 kg |
| Winding Voltage Class | 230V 3-phase low voltage |
| Rated Speed | 3000 RPM |
| Stack Length Code | 4-stack magnetic core |
| Encoder Type | Single-turn high-resolution absolute encoder, Hiperface protocol |
| Holding Brake | Without built-in electromagnetic holding brake |
| Overheat Protection | Built-in PTC thermistor temperature detection |
| Frame Size | Frame 130, 130 mm IEC standard flange |
| Mounting Style | FF metric standard flange mounting |
| Output Shaft | Standard keyed shaft, no shaft seal |
| Connector Type | SpeedTEC DIN right-angle connector, 180° rotatable |
| Ingress Protection | Motor body IP50, shaft end IP65 |
| Winding Class | High temperature resistant industrial winding |
| Model Code Explanation | MPM: Medium inertia servo motor series
A: 230V winding 130: 130mm frame flange 4: 4-section core stack F: 3000 RPM rated speed version S: Single-turn high-res absolute encoder J: Rotatable right-angle SpeedTEC connector 7: No holding brake 2: Keyed output shaft AA: Standard factory configuration |
| Main Advantages | Medium inertia rotor for large inertia loads; rotatable connector for convenient wiring; single-turn absolute encoder only needs single-turn homing after power on; high power density & large torque output |
| Typical Applications | Heavy-duty machine tool feed axes, large automated conveying equipment, auxiliary injection molding machines, heavy truss manipulators, metal cutting equipment, high-load positioning platforms |
FAQ
1.What is the maximum rotation angle of the MPM-A1304F-SJ72AA connector?
The The joint can rotate a maximum of 180 degrees.
2.What communication protocol is used by the MPM-A1304F-SJ72AA encoder?
Supported. The Single-loop high-resolution absolute encoder, Hiperface protocol
3.Does the output shaft of MPM-A1304F-SJ72AA have a flat key?
The With standard flat key shaft extension.
4.What is the rated rotational speed of the MPM-A1304F-SJ72AA?
The 3000 RPM
Looking for Original New MPM Series MPM-A1304F-SJ72AA Servo Motor 230V 3000 RPM
We supply this MPM-A1304F-SJ72AA mainly to system integrators and maintenance teams for replacement and retrofit projects.
Contact US to get a good prices now
