Overview
The AB Kinetix MPL MPL-B330P-SJ74AA Servo motor, three-phase, 460VAC, 5000 RPM. Frame 3, core stack length 76.2mm (3 inches), high-resolution absolute value encoder, with flat key output shaft, SpeedTEC DIN right-angle quick connector, 24VDC power-off retention electromagnetic brake, Class F insulation, 100mm IEC (FF) metric flange, body IP50, natural cooling and heat dissipation.
Specification
| Item | Parameter |
|---|---|
| Model | MPL-B330P-SJ74AA |
| Series | MPL Low-Inertia Brushless Servo Motor |
| Voltage Class | 460 VAC |
| Rated Speed | 5000 rpm |
| Continuous Stall Torque | 4.18 N·m |
| Peak Torque | 12.2 N·m |
| Feedback | Single-turn High-resolution Absolute Encoder (Hiperface) |
| Shaft | Keyed Shaft (No Standard Shaft Seal) |
| Connector | SpeedTEC DIN, Right Angle, 180° Rotatable |
| Brake | 24 VDC Holding Brake |
| Mount Flange | Frame3, 100 mm IEC Metric FF Mount |
| Enclosure Rating | IP50 (IP66 with optional shaft seal) |
FAQ
1.Does the MPL-B330P-SJ74AASpeedTEC connector type support angle rotation?
The Equipped with SpeedTEC DIN right-angle connector, it supports 180° angle rotation adjustment.
2.Is the output shaft of the MPL-B330P-SJ74AA a smooth shaft or a shaft with a flat key extension?
Supported. The The output shaft is a keyed shaft extension (with key), not a plain shaft.
3.What are the rated and maximum operating speeds of the MPL-B330P-SJ74AA?
The The rated speed and the maximum speed are both 5000 rpm.
4.Is the MPL-B330P-SJ74AA encoder type single-turn or multi-turn absolute value? What is the communication protocol?
The The encoder is a single-loop absolute encoder, and the communication protocol is Hiperface.
Looking for Original New MPL-B330P-SJ74AA Kinetix MPL Servo motor 460VAC 5000 RPM
We supply this MPL-B330P-SJ74AA mainly to system integrators and maintenance teams for replacement and retrofit projects.
Contact US to get a good prices now
