Overview
The Mitsubishi FX5UC: iQ-F ultra-thin modular compact PLC CPU main unit, DC24V power supply, 16-point transistor drain-type output, spring-free screwless clamping type wiring terminals, communication photo-isolation, 35mm standard DIN rail, 48.1mm ultra-thin size, IP20, installed only inside the control cabinet, terminal type RS485 RJ45 Ethernet
Specification
| Item | Specification |
|---|---|
| Model Name | FX5UC-32MT/DSS-TS |
| Series | MELSEC iQ-F FX5UC Ultra-compact CPU |
| Total Built-in I/O Points | 32 points (16 Input / 16 Transistor Output) |
| Output Type | MT: NPN Open Collector Transistor |
| Power & Input Type | DSS: DC24V Power Supply, Fixed Source Input (Non-switchable Sink) |
| Terminal Type | TS: Spring Clamp Screwless Terminal Block |
| Operating Power Supply | DC 20.4 ~ 26.4V |
| Operating Current | 0.5A |
| Internal 5V Bus Output Current | 0.72A |
| Overall Power Consumption | 5W |
| Built-in Digital Input | 16 points (X0~X17) |
| Input Signal | DC24V, Fixed Source Type Only |
| Input Current per Point | 4mA (DC24V) |
| Input Response Time X0~X5 | 2.5μs (High-speed dedicated) |
| Input Response Time X6~X17 | 30μs (Standard) |
| Digital Filter Range | 0 ~ 70ms adjustable |
| Isolation of Input Circuit | Photo-coupler isolation |
| Built-in Digital Output | 16 points (Y0~Y17), 8 points per common terminal |
| Rated Load Voltage | DC 5 ~ 30V |
| Rated Current per Output (Resistive Load) | 0.3A |
| Rated Current per Output (Inductive Load) | 0.1A |
| Max Current per Common Terminal | 0.8A |
| Total Max Output Current (2 groups parallel) | 1.6A |
| Off-state Leakage Current | ≤0.1mA @ DC30V |
| Output Response OFF→ON | ≤10μs |
| Output Response ON→OFF | ≤50μs |
| Basic Instruction Execution Speed | 34ns per LD instruction |
| Program Memory Capacity | 64K steps (Flash ROM, data retention without battery) |
| Timer T | 1024 points |
| Counter C | 1024 points |
| Data Register D | 8000 points |
| File Register R | 32768 points |
| Tag Memory Capacity | 120KB |
| ROM Storage Space | 5MB |
| External Storage Support | SD/SDHC Card (Max 4GB) |
| Supported Programming Languages | LD, ST, FBD, SFC, Structured Multi-program |
| Built-in High-speed Counter Channels | 8 channels total |
| Max Frequency (X0~X5 dedicated channels) | 200kHz |
| Max Frequency (General multiplex channels) | 10kHz |
| Counting Modes | Single-phase single/double count, AB-phase 4x multiplication |
| Built-in Positioning Axis | 4 independent axes (Y0/Y1/Y2/Y3 pulse output) |
| Max Pulse Output Frequency | 200kHz |
| Pulse Output Formats | Pulse/Direction, Forward/Reverse Pulse |
| Positioning Functions | Zero return, multi-speed positioning, electronic cam, synchronous follow-up |
| Built-in Communication Interfaces | 1 × RJ45 Ethernet, 1 × RS485 Terminal Port |
| Ethernet Supported Protocols | MC Protocol, SLMP, Modbus TCP, CC-Link IE Field Basic |
| RS485 Supported Protocols | Modbus RTU, Mitsubishi dedicated protocol, N:N Network |
| Max Local I/O Points (CPU + Local Extension Modules) | 256 points |
| Max Total Control Points (Local + Remote I/O) | 512 points |
| Mounting Standard | 35mm DIN rail |
| Unit Width | 48.1mm ultra-thin body |
| Operating Ambient Temperature | 0 ~ 55°C |
| Storage Temperature | -20 ~ 75°C |
| Ambient Humidity | 5 ~ 95%RH (Non-condensing) |
| Vibration & Shock Resistance | Compliant with IEC 61131-2 |
| Protection Class | IP20 (Installed inside control cabinet) |
| Certifications | UL/cUL, CE (EMC & RoHS), KC, Marine Certifications (LR/NK/DNV/ABS/BV/KR) |
| Difference from FX5UC-32MT/DS-TS | Input is fixed source type, cannot switch to sink type |
FAQ
1.What are the supply voltage and the overall power consumption of the FX5UC-32MT/DSS-TS?
The Power supply voltage: DC 20.4 – 26.4V; Overall power consumption: 5W
2.What is the maximum capacity of the SD card supported by FX5UC-32MT/DSS-TS?
Supported. The Supports SD/SDHC memory cards with a maximum capacity of 16GB; the new firmware is compatible with original 8GB and 16GB memory cards.
3.Does the FX5UC-32MT/DSS-TS come with several-axis pulse positioning output?
The Built-in 4-axis independent pulse positioning output (Y0/Y1/Y2/Y3)
4.Can the input of FX5UC-32MT/DSS-TS be switched to the open-collector connection?
The No, the DSS model is a fixed-source type input and cannot be switched to the depletion type.
