QRI2B2.B180B1 – Infrared flame detector, lateral, cable 180cm, stripped+ferrules+flange+clamp
| Delivery information | |
| Export Control Regulations | AL : N / ECCN : N |
| Standard lead time ex-works | 5 Day/Days |
| Net Weight (kg) | 0,226 Kg |
| Packaging Dimension | 11,30 x 16,40 x 8,80 |
| Package size unit of measure | CMT |
| Quantity Unit | 1 Pcs |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 90273000 |
| LKZ_FDB/ CatalogID | BT_Catalog |
| Product Group | QBA7 |
| Group Code | H5GA |
| Country of origin | Germany |
QRI2B2.B180B1 is an infrared flame detector launched by Siemens. It is specially designed for safety monitoring of industrial combustion scenarios and is the core safety component of industrial combustion equipment.
QRI2B2.B180B1 uses infrared detection technology, which can accurately identify flames such as fuel and gas, and has strong anti-interference, which can reduce false alarms caused by halogen lamps, welding equipment, etc. It is equipped with a self-test function and responds quickly. Some information shows that its response time is less than 0.5 seconds, and it can provide timely feedback on the flame status to trigger safety interlocks. Compatible – Extreme temperature range of 40°C to + 70°C, IP65 protection, withstands dust, moisture and other harsh industrial environments.
FAQ:
1.What are the dimensions of QRI2B2.B180B1?
The body size of QRI2B2.B180B1 is 125mm×76mm×44mm, and the weight is about 200g. Other overseas channels show that the dimensions of similar models in the same series are 2×2×2 inches (approximately 50.8mm×50.8mm×50.8mm), which may be caused by differences in different batches or marked calibers.
The standard connecting cable length of the QRI2B2.B180B1 detector is fixed at 180 cm, and the connecting cable has stripped terminals and wire hoops, and is used with flanges and clamps for installation and fixation, adapting to the installation interface requirements of most industrial combustion equipment.
2.What is the response time of QRI2B2.B180B1?
The core response performance of the QRI2B2.B180B1 detector body is less than 0.5 seconds as the main indicator. This parameter is also in line with its core positioning of adapting to harsh industrial scenarios and ensuring the safe operation of combustion equipment.
3.What are the installation methods of QRI2B2.B180B1?
The detector comes standard with a mounting flange and a clamp (clamp). During installation, the detector can be directly fixed on the burner through these two accessories. The two accessories adapt to different installation interface requirements. The installation operation is flexible and can meet the assembly standards of most industrial combustion equipment.
