Overview
HG-RR153 is a 1.5kW ultra-low inertia, high-response AC servo motor of the MELSERVO-J4 series. It has a high dynamic response, medium power, and high-precision servo drive unit. It is suitable for fast start and stop, and high-frequency reciprocating action equipment. The rotor inertia is only 1.9 kg·cm², and it accelerates and decelerates very quickly, enabling millisecond-level start, stop, and reversal. It comes standard with a 22-bit absolute encoder, with a single-turn resolution of 4.19 million pulses.
Specification
| Item | Details |
|---|---|
| Series | MELSERVO-J4, HG-RR (Ultra-Low Inertia) |
| Rated Power | 1.5 kW |
| Rated Torque | 4.8 N·m |
| Max. Torque | 11.9 N·m (≈2.5× rated, 1s) |
| Rated Speed | 3,000 rpm |
| Max. Speed | 4,500 rpm |
| Rotor Inertia | 1.9 kg·cm² (ultra-low) |
| Voltage Class | 3-phase AC 200 V class (200–240 V) |
| Encoder | Built-in 22-bit absolute encoder (4,194,304 p/rev) |
| Protection | IP65 (motor body) |
| Brake | Standard: No (brake version available as HG-RR153B) |
| Mounting | 100×100 mm flange |
| Weight | Approx. 5 kg… |
FAQ:
1.Which Mitsubishi servo driver is the HG-RR153 compatible with?
Pulse type: MR-J4-200A / MR-J4-200A4
Bus type: MR-J4-200B / MR-J4-200B4
2.What are the common reasons for an overload alarm on HG-RR153?
- Excessive mechanical load, stuck or abnormal resistance
- The acceleration and deceleration time is set too short and starts and stops frequently.
- Torque limit parameter set too low
- Motor and driver power do not match
- The transmission mechanism has large clearance, eccentricity or inconsistent installation.
- The motor has poor heat dissipation and the ambient temperature is too high.
- Encoder exception or parameter setting error
3.What is the difference between HG-RR153 and HG-RR153B?
The only difference between HG-RR153 and HG-RR153B is whether it has electromagnetic braking.
- HG-RR153: No electromagnetic brake
- HG-RR153B: With electromagnetic power-off braking (brake), it automatically locks the shaft when power is off to prevent falling.
Looking for Original New HG-RR153 AC Servo Motor 1.5kW MELSERVO HG Series IP65
We supply this HG-RR153 mainly to system integrators and maintenance teams for replacement and retrofit projects.
Contact US to get a good prices now !
