Overview
The MP-Series MPL-B640F-SJ72AA 460V AC Servo Motor – Three-phase high-voltage model. Standard shaft extension with flat key, without oil seal. Hiperface single-turn single-rotation high-precision absolute value encoder Size 6, 215mm IEC metric flange, FF free installation hole. SpeedTEC DIN right-angle rotary joint, cable can be freely turned 180°. Basic protection IP54; optional shaft seal can reach IP66. Indoor control cabinet installation. Overall weight 13.61 kg.
Specification
| Item | Specification |
|---|---|
| Model | MPL-B640F-SJ72AA |
| Series | Rockwell MP-Series MPL Low Inertia Brushless Servo Motor |
| Rated Armature Voltage | 460V AC |
| Frame Size | Size 6, 215mm metric flange |
| Magnet Stack Length | 101.6 mm (4.0 inch) |
| Max Speed | 3000 RPM |
| Continuous Stall Torque | 36.7 N·m |
| Encoder Type | Hiperface Single-turn Absolute Encoder |
| Encoder Resolution | 1024 Sin/Cos sine/cosine signals |
| Shaft Type | Keyed standard shaft extension, no shaft seal |
| Brake | No built-in 24V holding brake |
| Connector | SpeedTEC DIN right-angle, 180° rotatable quick connect |
| Mount Flange | IEC FF standard free mounting holes |
| Net Weight | 13.61 kg |
| Protection Class | IP54 (IP66 optional with shaft seal) |
| Operating Temp | 0 ~ 40℃ |
| Compatible Drives | Kinetix 2000 / 6000 / 7000 high voltage drives |
| Certifications | UL, CSA, CE |
FAQ
1.What is the distance between the mounting holes of the 6-inch MPL-B640F-SJ72AA base flange?
The Size 6 base, the diameter of the pitch circle of the flange mounting bolts (hole spacing) is 215mm (IEC FF standard flange).
The installation screws are evenly distributed on the pitch circle of φ215mm.
2.What is the maximum rated speed of the MPL-B640F-SJ72AA?
Supported. The The maximum rated rotational speed is 3000 revolutions per minute (3000 RPM).
3.How much rotation adjustment in degrees is supported by the MPL-B640F-SJ72AASpeedTEC DIN connector for changing the outlet direction?
The Supports 180° bidirectional rotation to adjust the outlet direction.
It can be rotated 90° to the left / right from the reference position, totaling a 180° adjustment range, suitable for different wiring directions.
4.What is the net weight of the entire MPL-B640F-SJ72AA motor in kilograms?
The The net weight of the entire machine is 13.61 kg (excluding the outer packaging and the standard weight of the motor alone).
Looking for Original New MP-Series MPL-B640F-SJ72AA 460V AC Servo Moto
We supply this MPL-B640F-SJ72AA mainly to system integrators and maintenance teams for replacement and retrofit projects.
Contact US to get a good prices now
