2711P-T7C21D8S PanelView Plus 7 DC24V Touch Screen LCD

Overview

The AB PanelView Plus 7 Standard 7 Terminal , 6.5-inch TFT color LCD touch screen HMI, VGA 640×480 resolution, WinCE 6.0 system, Ethernet port, DC 24V power supply, LED backlight, SD card slot, supports hot-swappable expansion storage, RTC real-time clock, front panel IP66, back panel IP20, for use only inside the control cabinet, total weight 1.35 kg, panel embedded installation.

Specification

Item	Specification
Model	2711P‑T7C21D8S
Series	PanelView Plus 7 Standard Terminal
Display	6.5″ Color TFT‑LCD, 4:3
Resolution	640 × 480 (VGA), 300 nits
Backlight	LED, 50000 h @40℃ to half brightness, non‑replaceable
Touch Screen	Analog resistive, ≥1 million presses
RAM	512 MB
Flash Memory	512 MB total, ~80 MB user application space
Operating System	Windows CE 6.0
Real‑Time Clock	RTC, CR2032 battery backup, min.4‑year life
Power Input	18‑30 VDC, nominal 24 VDC
Max Power Consumption	50 W (2.1 A @24 VDC)
Ethernet	1×10/100 Base‑T, EtherNet/IP, IEEE1588, no DLR
USB Ports	1×USB2.0 Host‑A, 1×USB Device‑B
External Storage	SD card slot (1784‑SDx series supported)
Dimension(W×H×D)	215 mm × 173 mm × 56.5 mm
Panel Cutout(W×H)	184 mm × 142 mm
Net Weight	1.35 kg
Front‑panel Rating	IP66, NEMA 4/4X‑12‑13
PCB Conformal Coating	No (Standard version)
Operating Temp	0℃～+55℃
Storage Temp	‑20℃～+70℃
Certifications	cULus, CE, ATEX Cat.3
Programming Software	FactoryTalk View Machine Edition

FAQ

1.What type is the 2711P-T7C21D8S touchscreen? What are the theoretical pressing lifespan and trigger pressure parameters?

The

• Touch screen type: Analog resistive touch screen
• Theoretical pressing life: ≥ 1,000,000 presses
• Trigger pressure: Approximately 100g

2.What are the overall length, width and depth dimensions of the 2711P-T7C21D8S machine, the size of the panel holes on the cabinet, and the net weight of the entire machine?

Supported. The

• Overall machine dimensions (width × height × depth, mm): 212 mm × 170 mm × 5 mm
• Panel opening size of the cabinet (width × height, mm): 184 mm × 142 mm
• Net weight of the entire machine: 1.35 kg

3.What are the capacities of the running memory, the total flash memory, and the user-available application storage space for 2711P-T7C21D8SRAM?

The

• RAM running memory: 512 MB
• Total flash storage capacity: 512 MB
• User available application storage space: approximately 80 MB

4.What is the version of the embedded operating system installed in the 2711P-T7C21D8S?

The

• Windows CE 6.0 (Embedded Version)
• Configuration programming software: FactoryTalk View Machine Edition (FTView ME)
