Overview
The AB 2711P-RDT10C PanelView Plus Series – 10.4-inch TFT color LCD with 640 × 480 (VGA) resolution, analog resistive touch screen, CCFL backlight, backlight lifespan ≥ 50,000 hours, embedded panel installation. Dimensions: Width 329 mm × Height 248 mm × Depth 55 mm, Net weight 2.6 kg.
Specification
| Item | Specification |
|---|---|
| Model | 2711P-RDT10C |
| Product Family | PanelView Plus 1000 Display Module |
| Product Type | Replacement Touch Display Assembly (No CPU/Power Module) |
| Display Size | 10.4 inch Color TFT LCD |
| Resolution | 640 × 480 (VGA) |
| Color Depth | 18-bit Color |
| Backlight | CCFL, Min. 50,000 hrs @ 40°C to half brightness |
| Touch Screen | Analog Resistive Touch |
| Touch Lifespan | ≥ 1,000,000 actuations |
| View Area | 211 mm × 158 mm |
| Front Panel Rating | IP65, NEMA Type 12,13,4X (Indoor) |
| Overall Dimension (W × H × D) | 329 × 248 × 55 mm |
| Panel Cutout Size | 305 × 224 mm |
| Net Weight | Approx. 2.6 kg |
| Operating Temperature | 0 ~ +55 ℃ |
| Storage Temperature | -25 ~ +70 ℃ |
| Operating Altitude | Up to 2000 m (no derating) |
| Shock Resistance | 15 g, 11 ms |
| Compatible Unit | PanelView Plus / PanelView Plus 6 10.4” Touch Terminals |
| Required Matching Module | 2711P-RPxx Logic/Power Module |
| Configuration Software | FactoryTalk View Machine Edition |
| Lifecycle Status | Discontinued (EOL) |
FAQ
1.Is the 2711P-RDT10C product a complete terminal or a display replacement module?
The The display replacement module is not a complete entire machine terminal. It does not include the CPU and power logic module. It can only function when paired with the 2711P-RPxx series logic power module.
2.What type of touchscreen does 2711P-RDT10C use, and what is the theoretical pressing lifespan?
Supported. The Using an analog resistive touch screen, the theoretical pressing life is ≥ 1 million times.
3.What is the front panel protection level of 2711P-RDT10C and what is its NEMA rating?
The The front panel has an IP65 protection rating and a NEMA type 12, 13, 4X rating (for indoor use)
4.What is the screen size of 2711P-RDT10C in inches?
The 10.4 inches, TFT color LCD
Looking for Original New 2711P-RDT10C AB PanelView Plus Display Module 10.4 Inches TFT Color LCD
We supply this 2711P-RDT10C mainly to system integrators and maintenance teams for replacement and retrofit projects.
Contact US to get a good prices now
