2711 PanelView Plus 6 Terminal 2711P-T7C4D9 HMI 7 Inch

Manufacturer	Allen Bradley
Part Number	2711P-T7C4D9
Product Type	Panel

Send Inquiry

Global Delivery

12 months Warranty

100 % Authentic Parts

Dispatch immediately

24 hours to 7 Days

Hassle-free return

Description
Reviews (0)

Overview

2711P‑T7C4D9 is a PanelView Plus 6 Series 700 7-inch color touchscreen, 640×480, analog resistive touchscreen, CCFL backlight (≥50,000 hours), input: touch; power supply: 18–32 VDC; operating temperature: 0–55°C; protection: front IP65, rear IP20, communication: 1×EtherNet/IP (RJ45), 1×RS‑232, 2×USB host; installation: wall mounting/direct installation, size 246×179×55 mm, opening 154×220 mm.

Parameter

Model	Key Specifications	Special Differences	Status
2711P-T7C4D9	700 Series; 7-inch touch; 1×EtherNet/IP, 1×RS-232, 2×USB; 512MB RAM/Flash; 18-32VDC; IP65(Front)/IP20(Rear)	Basic configuration for general industrial monitoring	Discontinued
2711P-T7C22D9P (Replacement)	700 Series; 7-inch touch+22 function keys; Same as T7C4D9 for other specs	Suitable for quick hard-key operation; No config modification for replacement	Active
2711P-T10C4D9	1000 Series; 10.4-inch touch; Same as T7C4D9 for other specs	Larger screen for big-picture monitoring; Larger size & cutout	Active
2711P-K12C4D9	700 Series; 12-inch touch+12 function keys; Same as T7C4D9 for other specs	Fit for complex operations & data entry (touch+keyboard)	Active
2711P-B15C4D9	1500 Series; 15-inch touch; Support optional communication modules; Same as T7C4D9 for other specs	HD large screen for central control; Support web remote monitoring	Active

FAQ:

1.What industrial network protocols does 2711P-T7C4D9 support? Can it be seamlessly connected to ControlLogix/CompactLogix series PLC?

The core supports the EtherNet/IP protocol, and is equipped with an RS-232 interface to support the corresponding serial communication protocol; it can be expanded to support DH+, ControlNet and other protocols through optional expansion modules (such as DH+/ControlNet modules).
Can be seamlessly connected to ControlLogix/CompactLogix series PLC. Because they are all based on Rockwell EtherNet/IP industrial Ethernet architecture, no additional protocol conversion modules are required. Communication configuration can be quickly completed through FactoryTalk View Machine Edition configuration software to achieve data interaction and device control.

2.- What are the memory configuration (RAM/flash memory) and operating system of 2711P-T7C4D9? Are there any requirements for the version of the configuration software?

Memory configuration: 512 MB RAM + 512 MB Flash memory
Operating system: Windows CE 6.0
Configuration software version requirements: FactoryTalk View Machine Edition is required. It is recommended to use a stable version compatible with Windows CE 6.0 (such as v6.1 and above) to ensure that there are no abnormalities in model identification, function configuration and communication adaptation.

3. 2711P-T7C4D9 Compared with 2711P-T10C4D9 (10.4 inches) and 2711P-B15C4D9 (15 inches), what are the core differences of 2711P-T7C4D9?

Specification Category	2711P-T7C4D9	2711P-T10C4D9	2711P-B15C4D9
Display Specification	7-inch, 640×480 resolution, CCFL backlight	10.4-inch, 640×480 resolution, CCFL backlight	15-inch, 1024×768 HD resolution, CCFL backlight
Expansion Capability	No web remote monitoring; Does not support extended communication modules	No web remote monitoring; Does not support extended communication modules	Supports web browser remote monitoring; Expandable with DH+/ControlNet and other communication modules
Dimensions & Cutout Size	Dimensions: 246×179×55 mm; Cutout size: 154×220 mm (smallest)	Larger dimensions and cutout size than 2711P-T7C4D9	Largest dimensions and cutout size among the three models
Consistent Core Configurations	512 MB RAM + 512 MB Flash; Windows CE 6.0 OS; Basic communication interfaces (1×EtherNet/IP, 1×RS-232, 2×USB Host); Front IP65/ Rear IP20 protection level
