Overview
20G11ND040JA0NNNNN is an air-cooled AC drive of the PowerFlex 755 series, with pre-charged AC input, with common mode (CM) jumper, filtered, built-in EtherNet/IP Ethernet communication port, open type (Open Type), no DC bus terminals.
Specification
| Item | Specification |
|---|---|
| Rated Output Current (ND, Normal Duty) | 40 A |
| Suitable Motor Power (ND, 480V) | 25 HP / 18.5 kW |
| Suitable Motor Power (HD, Heavy Duty) | 20 HP / 15 kW |
| Input Voltage | 3‑phase 480V AC |
| Control Method | Vector control (V/Hz and vector modes selectable) |
| Protection Degree | IP20 / Type 1 (Open Type) |
FAQ:
1.Is 20G11ND040JA0NNNNN suitable for wall mounting or cabinet installation??
20G11ND040JA0NNNNN has an Open Type structure and is not suitable for direct wall-mounting. The standard installation method is cabinet installation.
2.20G11ND040JA0NNNNN What do the codes in the parts number mean?
| Code Section | Description |
|---|---|
| 20G1 | PowerFlex 755 Series AC Drive |
| 1 | Standard Unit Configuration |
| N | NEMA Frame |
| D | Voltage Class: 480V 3-phase |
| 040 | Rated Output Current: 40 A |
| JA | Open Type, Built-in EtherNet/IP, with Pre-charge, No DC Bus Terminals |
| 0 | Standard Configuration |
| NNNNN | No Options (No Filter, No Encoder, No Communication Options, etc.) |
3.How many kilograms does 20G11ND040JA0NNNNN weigh?
20G11ND040JA0NNNNN weighs approximately 12 kg.
Looking for Original New 20G11ND040JA0NNNNN PowerFlex 755 AC Drive 40HP 480V 3 Phase ?
We supply this 20G11ND040JA0NNNNN mainly to system integrators and maintenance teams for replacement and retrofit projects.
Contact US to get a good prices now !
