Overview
The AB PowerFlex700 AC Drive 20BD125A3ANNADD0 – Three-phase, 480V, 75kW, 100HP. Continuous output of 125A at 120V AC IO terminal + relay output. LCD digital keyboard, HIM panel, IP20 / NEMA Type 1. Zero stacking and side-by-side installation. PCB whole machine has three-layer protection coating. Overall width: 308.9 mm, height: 644.5 mm, depth: 275.4 mm. Net weight: 37.19 kg.
Specification
| Item | Specification |
|---|---|
| Brand | AB |
| Series | PowerFlex 700 AC Drive |
| Catalog Number | 20BD125A3ANNADD0 |
| Frame Size | Frame 5 |
| Input Power | 3‑Phase 480V AC ±10%, 50/60Hz, 6‑Pulse Rectifier |
| Continuous Rated Output Current | 125 A |
| 110% Overload (1 min) | 138 A |
| 150% Overload (3 sec) | 163 A |
| Normal Duty Motor Rating | 100 HP (75 kW) |
| Heavy Duty Motor Rating | 75 HP (56 kW) |
| Output Voltage | 0 ~ 480 V 3‑Phase PWM |
| Adjustable Carrier Frequency | 2 kHz ~ 16 kHz |
| Control Modes | V/F Open Loop, Sensorless Vector (SVC) |
| Encoder Support | Not available |
| I/O Operating Voltage | 120V AC Digital Input & Relay Output |
| EMC Filter | Built‑in Class 2 CE EMC Filter with Common Mode Choke |
| Dynamic Brake IGBT | Not integrated |
| Internal Brake Resistor | Not equipped |
| HIM Configuration | Built‑in LCD Digital HIM Keypad |
| PCB Board | Conformal Coated |
| Cooling System | Forced air cooling, replaceable cooling fan |
| Enclosure Rating | IP20 / NEMA Type 1 |
| Operating Temperature | 0 ~ 50 °C (No derating ≤1000 m altitude) |
| Full Load Noise Level | Approx. 71 dB |
| Ramp Function | Independent 0~3600s Accel/Decel, S‑Curve Ramp |
| Stop & Brake Modes | DC Braking, Coast Stop, Fast Stop |
| Protections | Overcurrent, Overvoltage, Undervoltage, Overtemperature, Motor Overload, Ground Fault, Phase Loss, Output Short Circuit |
| Communication | No onboard port; Optional add‑on cards (DeviceNet, EtherNet/IP etc.) |
| Standard Functions | Multi‑speed, Fault Log, Parameter Copy, Oscillation Control, Sleep Energy Saving |
| Mounting | Zero stack side‑by‑side installation |
| Overall Dimensions (W×H×D) | 308.9 mm × 644.5 mm × 275.4 mm |
| Net Weight | 37.19 kg (82.0 lbs) |
| Packed Shipping Weight | 42.18 kg (93.0 lbs) |
| Product Status | Discontinued since June 2023 |
FAQ
1.Does the 20BD125A3ANNADD0 inverter support external encoder closed-loop control?
The This machine does not have an internal encoder feedback terminal. It is not factory-configured to support direct connection of an encoder for closed-loop control.
2.Does the 20BD125A3ANNADD0 circuit board have a PCB anti-corrosion and anti-oxidation coating?
Supported. The Equipped with HumiSeal 1B73 acrylic three-layer anti-corrosion coating, it has the functions of moisture-proofing, dust-proofing and corrosion resistance protection.
3.What are the protection level and cabinet standard for 20BD125A3ANNADD0?
The
- Protection level: IP20
- Cabinet standard: NEMA/UL Type 1
- This model is only suitable for installation inside the control cabinet and cannot be used outdoors directly.
4.Which type of human-machine operation panel should be equipped with 20BD125A3ANNADD0?
The
- 20-HIM-A3 Local Standalone LCD All-Digital Keypad Operating Panel.
- Advantages: Equipped with a liquid crystal display, a complete digital keyboard, supporting parameter reading and writing, parameter copying, fault viewing, and point-and-motion speed adjustment.
Looking for Original New 20BD125A3ANNADD0 PowerFlex 700 AC Drive 75kW 100HP 125A 480V
We supply this 20BD125A3ANNADD0 mainly to system integrators and maintenance teams for replacement and retrofit projects.
Contact US to get a good prices now
