Product Introduce
2080-LC50-48QWB is a Micro850 series compact PLC with 48 onboard I/O points, supports EtherNet/IP, 5 plug-in ports, can be connected to 2080 series I/O modules, up to 6 high-speed counters (HSC), and supports LD/FBD/ST programming.
Parameter
| Parameter | 2080‑LC50‑48QWB | 2080‑LC50‑48QVB | 2080‑LC50‑48AWB | 2080‑LC50‑24QWB | 2080‑L50E‑48QWB |
|---|---|---|---|---|---|
| Series | Micro850 | Micro850 | Micro850 | Micro850 | Micro850 (Replacement) |
| Total I/O | 48 (28 inputs, 20 outputs) | 48 (28 inputs, 20 outputs) | 48 (28 inputs, 20 outputs) | 24 (14 inputs, 10 outputs) | 48 (28 inputs, 20 outputs) |
| Input Type | 28×24V DC/AC; 6×HSC | 28×24V DC/AC; 6×HSC | 28×24V DC/AC; 6×HSC | 14×24V DC/AC; 6×HSC | 28×24V DC/AC; 6×HSC |
| Output Type | 20×Relay | 20×Relay | 20×24V DC Source | 10×Relay | 20×Relay |
| Max HSC | 6 | 6 | 6 | 6 | 6 |
| PTO Axes | 0 | 3 | 0 | 0 | 0 |
| Plug‑in Slots | 5 | 5 | 5 | 5 | 5 |
| Expansion I/O | Up to 4 modules | Up to 4 modules | Up to 4 modules | Up to 4 modules | Up to 4 modules |
| Comm Ports | USB, RS232/485, EtherNet/IP | USB, RS232/485, EtherNet/IP | USB, RS232/485, EtherNet/IP | USB, RS232/485, EtherNet/IP | USB, RS232/485, EtherNet/IP |
| Power Input | 24V DC | 24V DC | 24V DC | 24V DC | 24V DC |
| Dimensions (H×W×D) | 90×238×80 mm | 90×238×80 mm | 90×238×80 mm | 90×158×80 mm | 90×238×80 mm |
| Weight | ≈0.725 kg | ≈0.725 kg | ≈0.725 kg | ≈0.5 kg | ≈0.725 kg |
| Lifecycle | Discontinued (2023‑07‑31) | Active | Active | Active | Active |
FAQ:
1. What is the replacement model after 2080-LC50-48QWB is discontinued? Are the functions the same? Can it be directly replaced?
2080-LC50-48QWB will be discontinued on July 31, 2023. The replacement model is 2080-L50E-48QWB, and the supporting model is 2080-L50E-48QWBK. The two have the same I/O configuration, communication interface, and expansion capabilities, and can be seamlessly replaced and compatible with original programs and wiring.
2. What is the maximum load capacity of the relay output of 2080-LC50-48QWB?
The onboard relay outputs of the 2080‑LC50‑48QWB are 2A maximum per point (resistive load) and rated at 240V AC or 24V DC; the total load of all 20 relay outputs does not exceed 10A
3.What is the maximum frequency of the high-speed counter of 2080-LC50-48QWB?
The 2080‑LC50‑48QWB’s onboard high-speed counter (HSC) has a maximum frequency of 100 kHz per channel (single-ended/differential), a total of 6 HSCs, and is only available in 24V DC input mode
